YU1QT MOXON STACKS

Want gain?  How about 2 element Stacked Moxons?



Recently, there have appeared several posts on our Message Board about stacking Moxon antennas.  Andra, YU1QT, has graciously sent in several plans and plots for stacking Moxon's for a variety of bands.  Shown below are plans for 2 over 2 element wire Moxons for 40 and 15 meters.  Gain shown incorporates eznec ground gain, +5.5db over freespace.

If you build them, there will be DX.





40 Meter Moxon mounted on the tower at 45/28 meter levels

7 on the ground.jpg

2 element 40 meter Moxon under construction



 Moxon 7 Andra Tafro.jpg

Andra (left) and Tafro working on the 40 meter moxon



Emil in trailer.jpg

Emil, E71A, working DX high above Sarajevo (shown below)


2 x 2el Moxon W4RNL 7 V plot dia.png

Notice the 13 dbi gain!!

2 x 2el Moxon W4RNL 7 H plot dia.png

2 x 2el Moxon W4RNL 7 SWR.png



15 Meter Moxon mounted on the tower at 15/7 meter levels



2 x 2el Moxon W4RNL 21 V plot dia.png

2 x 2el Moxon W4RNL 7 H plot dia.png



2 x 2el Moxon W4RNL 21 SWR.png
